Acoustic Image DoubleShot 2R Combo 690 D2R
Combo for Double Bass
Technical Data
- Manufactured by Acoustic Image
- Released in 2020
- Average price : $2194
- Consists of DoubleShot Speaker Cabinet and Clarus 2plus 601IA amplifier
- Includes speaker cable
- Consists of 2x 10" woofer and 1x side-firing 5" midrange speaker
- Well suited for acoustic and electric instruments like guitar, double bass, keyboard etc.
- Rubber dampers allow the top to be mounted on the DoubleShot
- 600 watts
- Impedance: 4 Ohm
- Max SPL: 118 dB/m
- Frequency range: 40 - 16,000 Hz
- Input: Neutrik Speakon with pole 1 assignment
- Diameter: approx. 30.5 cm
- Width: approx. 28 cm
- Weight : 6.8kg
- 2 Channels
- 600 Watts
- 650 Watts of music power into 4 ohms
- Selectable reverb and delay effects, each with adjustable level and intensity
- 4-Band EQ
- Adjustable low cut filter
- Effects loop
- Direct-out with switchable 10 dB boost/cut
- Pre/post and ground lift switches
- Mute switch
- Limiter
- Input signal control per channel
- Phase inversion and adjustable low cut for both channels
- Separate XLR and 6.3 mm jack inputs that can be operated simultaneously
- Switchable 48V phantom power and 10 dB boost/cut for the microphone inputs
- Mono or stereo output from the preamplifier
- Headphone output
- Loudspeaker outputs with Speakon connectors
- Slanted front chassis
- Weight : approx. 1.8kg
- Dimensions: approx. 25.9 x 20.8 x 8.9 cm
