Acoustic Image UpShot 2R Combo 680 U2R
Amplifier set for double bass
Technical Data
- Manufactured by Acoustic Image
- Released in 2021
- Average price : $1950
- Consisting of Upshot Speaker Cabinet 690 EX and Clarus 2plus 601IA amplifier
- Speaker configuration: 10" woofer radiating upwards
- Suitable for acoustic and electric instruments like guitar, double bass, keyboard etc.
- Power handling: 300 W
- Impedance: 8 Ohm
- Frequency range: 40 to 4.000 Hz
- Max SPL: 113 dB/m
- Dimensions (Ø x H): Approx. 30.5 x 15.3 cm
- Weight : Approx. 6.8kg
- Input: Neutrik Speakon with pole 1 assignment
- 2 channels
- 650 W music power at 4 ohms
- Reverb and delay effects, each with level and intensity controls
- Inputs: 6.3 mm jack, LoZ and HiZ for optimum adaptation to Piezo pick-ups
- Low weight of only approx. 1.8 kg
- Compact dimensions (W x D x H): approx. 25.9 x 20.8 x 8.9 cm
- Slanted front chassis
- Separate XLR and 6.3 mm jack inputs that can be operated simultaneously
- Switchable 48 V phantom power and 10 dB boost/cut for the microphone inputs
- Input signal control per channel
- 4-band EQ
- Phase reversal and adjustable low cut for both channels
- Effects loop
- Direct out with 10 dB boost/cut
- Pre/post and ground lift switches
- Headphone output
- Limiter
- Mute button
- Mono or stereo output from the preamplifier
- Speaker outputs: Speakon
- Incl. Mounting bracket and speaker cable
