ADDAC 306 VC Transitions
Eurorack Module
Latest User Reviews
Perfect for live sets
It is a fairly basic module but extremely useful.
Setting two different states and modulating between those is a strong feature.
eg. one channel for envelope decay, a second one for filter frequency, a third one for fx dry wet ... and the passing from one state to the next is as easy as a crossfader.
You can find endless uses to this little device.
Technical Data
- Manufactured by ADDAC
- Released in 2020
- Average price : $154
- 5-Channel CV source & patch controller
- Voltage range per channel definable via "Minimum" and "Span" controls (offset to minimum)
- Voltage curve of each channel selectable via switch (minimum to maximum or vice versa)
- Transition slider controls the CV curve of all 5 channels simultaneously
- Output voltage per channel selectable between +5V and +10V
- CV In for transition controller
- 5 x CV Out
- Current consumption: 40 mA (+12 V) / 20 mA (-12 V)
- Width: 8 HP
- Depth: 40 mm
