ADJ Mega 64 Profile Plus

Technical Data

• Manufactured by ADJ
• Released in 2015
• Average price : $157
• Compact and flat design
• For brightening and illuminating stages and walls with the wash effects
• 12 Bright 4-W QUAD LEDs (RGB + UV, 4-in-1)
• Can be placed directly on the floor or without mounting bracket integrated inside truss, since the inputs and outputs for power and DMX are not located on the back, but on the side
• Smooth RGB + UV colour mixing without RGB + UV shade
• Beam angle: 25°
• 5 DMX Channel modes: 4/5/6/9/10 channels
• 5 Operating modes: RGB + UV dimmer, sound control, Auto Run (16 colour changing, 16 colour-fade and colour change & fade-combi programs), static colours and DMX control mode
• Stand-alone or master/slave configuration
• 4-Button DMX LED display
• 64 Built-in colour macros (colour shades)
• Flicker-free
• DMX-512 Protocol
• LED with pulse and strobe effect
• Connection via 3-pin XLR cable
• Electronic dimming: 0 - 100%
• Mounting bracket for attachment to truss, the wall or on the floor
• Long-lasting LEDs (50,000 hours of operation)
• Power consumption: Max. 54 W
• IEC Input and output for AC connected in series on the back of the device (up to 12 Mega 64 profiles plus devices)
• Switching power supply: AC 100 V-240 V / 50/60 Hz
• Dimensions (L x W x H): 261 x 260 x 110 mm
• Weight : 2.1kg
