ADJ Ultra Beam Bar 12CW

Technical Data

• Manufactured by ADJ
• With 12 x 20 W LEDs
• Colour temperature: 6200 K (cool white)
• Expected lifespan of the LEDs approx. 50,000 hours.
• Luminous flux: 1340 lumen
• Beam angle: 5° (per pixel)
• Pixel-pitch: 85.5 mm
• Control: ADJ UC-IR remote control
• Manual
• Stand Alone: 13 show programmes
• Sound-Trigger and DMX-512 / RDM / RDM NET
• DMX channel modes: 1, 3, 12, 14 and 19 channels
• Display: OLED with 4 buttons
• LED refresh rate: 1.9 Hz
• 6 selectable dim modes: Standard, Stage, TV, Architecture, Theatre & Stage 2
• 4 Selectable dimmer curves
• Electronic dimming: 0-100 %
• DMX connection: XLR 5 pole In / Out
• Power connection: Power Twist In / Out
• Multi-voltage operation: AC 100 V-240 V, 50 / 60 Hz
• Power consumption: 60 W
• Up to 32 devices can be operated in a daisy chain
• Protection class IP20
• Dimensions (L x W x H): 8 x 108 x 11 cm
• Weight : 3.4kg
• 1 x Power Twist power supply cable
• 1 x UC-IR remote control
• 1 x 5° Beam Filter set (mounted)
• 1 x Safety cable
• 2 x Hand knob with threaded stud
• 2 x Stand / mounting bracket
