Audiowerkzeug MeDi

Media DI Box for Laptop, PC, CD, DVD

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Audiowerkzeug
Released in 2013
Average price : $160
Suitable for uncomplicated balancing, potential separation and interference-free transmission of modern media devices such as laptops, stationary PCs, CD and DVD players to professional sound systems
Stereo signals are mono-summed in the integrated circuit and are available in the best quality without hum
Jack and RCA inputs (L / R)
High-quality high-end transformer
High bandwidth and best insulation
Excellent output balance
High level
Antimagnetic shielding
Compact, sturdy aluminium housing
Ratio: 10: 1
Inputs: 6.3 mm jack and RCA
Outputs: 6.3 mm jack Link Out, XLR balanced
Frequency response: 10 Hz - 50 kHz ± 3dB at +20 dB input level, 15 Hz - 50 kHz ± 3dB at +30 dB input level Relative to 2.2k? Terminating resistor and 3.3 nF load (= 50 m multicore)
Insulation capacity of the transformer: 1,500 VAC @ 50 Hz 1min
Output balance according to IEC:> 120 dB @ 50 Hz,> 90 dB @ 10 kHz
Measurements (W x H x D): 40 x 50 x 100 mm
Weight : 330g
Handmade in Germany
