Avid Pro Tools Carbon
DSP Audio Interface for Pro Tools
Latest User Reviews
ProTools Carbon - New Studio Heart!
I've ditched my HDX Card, all my Focusrite I/O Gear, Monitor Controller, Headphone Amp, Big Rack Cabinet and replaced it with 1U ProTools Carbon! (I've even made a profit by selling the gear its replaced. I've also gained 5U of rack space.
I installed it from my Avid account and it pretty much configured itself once I selected it as Playback Engine in Pro Tools. Done.
It has all my synths going in, a couple convenient instrument inputs on the front and 4 headphones out which I am using for headphones but have also assigned a pair to use for a second pair of monitors which are in front of my synths. The main monitors are powered from the back.
It looks good and I have to say, I notice an improvement in my overall sound production. It doesn't show any signs of stress at all when running ProTools.
It does kick out a fair bit of heat which despite the special air flow fans inside it is said to have but it is probably not as much heat as all the units combined that I have just removed. So it is not big enough of an issued to warrant further comment but it will kick out some heat, beware.
A great bit of kit at an absolutely crazy price considering what it does. My set up shrunk and it is easier to configure now, since all I am doing is selecting it as my audio interface in ProTools and then plugging in instruments and monitors and thats it. Nothing else!
Crazy good and definitely a way forward, love the hybrid function not that I have had to do anything to use it as it is just automatic.
Technical Data
- Manufactured by Avid
- Released in 2020
- Average price : $4389
- 8 HDX DSP processors (2.8 GHz)
- 32 bit / 192 kHz
- Dynamic range (A-weighted): 120 dB
- THD+N (0.0003%): -110 dB
- Frequency range (±0.1 dB): 20 - 20000 Hz
- Dimensions: 19" / 1U
- System requirements: Pro Tools 2020.11, MacOS Catalina 10.15.6 or later, Ethernet connection or adapter from Thunderbolt to Ethernet
- Includes Pro Tools Ultimate software perpetual license with 12 months Upgrade and Support Plan and comprehensive software package (download), power cable, Ethernet cable, rack screws and rubber feet
- 8 Combo inputs (XLR/jack, balanced), 4 of them with variable Z
- 8 Line inputs (25-pin D-sub balanced)
- 2 Variable Z instrument inputs on the front (6.3 mm jack, unbalanced)
- 8 Line outputs (25-pin D-sub, balanced)
- 2 Monitor outputs (6.3 mm jack, balanced)
- 4 Headphone outputs on the front (6.3 mm jack), 200 mW at 32 ohms
- ADAT I/O: 16 Channels @ 44.1 – 48 kHz, 8 Channels @ 88,2 – 96 kHz, 4 Channels @ 176.4 – 192 kHz
- Word clock input/output
