Behringer DI4000 V2
Active 4-channel Di-Box
Latest User Reviews
Not Good for Instruments
Editing this review:
At first, I disliked this DI box - since it seemed to warm the low end a lot. However, once I learned how to use the onboard features (ground lift, pad etc) the sound clean up tremendously.
So 50/50 - I was a little unfair initially, but also the design could probably be improved to be more intuitive.
Works well for my purposes
I am using this to interface with the TRRS (intended to be used for phone) I/O of a Rodecaster pro, which is otherwise very sensitive to ground loop noise.
Rode AI-1 monitor outputs -> two channels of the Berringer DI -> TRRS audio inputs.
TRRS audio output -> Berringer DI -> ATEM Mini video switcher.
Ground lift on all channels almost completely eliminates horrible ground loop noise.
I am using the +20 dB on 2 channels and the sound remains quite clean.
The sound is not quite as clean as some of the really high end DIs but god value for money and does the job well.
Technical Data
- Manufactured by Behringer
- Released in 2020
- Average price : $170
- Level shifter
- Gain switch +20 dB for pre-amplification of low-level signals
- Switchable phase
- Switchable high-cut filter (8 kHz) for guitars
- Ground lift switch
- 4 x XLR and jack inputs
- 4 x Jack link outputs
- 4 x XLR outputs
- Impedance: 240 ohms
- Max.output level: + 20dBu
- Frequency response: 23 - 69,000 Hz
- Installation depth: 136 mm
- Design: 19" / 1 U
- Weight : 2.1kg
