Behringer TD-3-MO-Bk

Analog Bass Line Synthesizer

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Behringer
Average price : $238
Extended version of the TD-3 with many new features
Control knobs for Soft Attack, Normal- and Accent-Decay, Filter Tracking, Slide Time and Filter FM
Switchable Sub Oscillator
Accent Sweep and Sweep Speed switchable in 3 steps
Muffler (VCA soft clipping) switchable in 2 steps
Manual Accent trigger button
Filter cutoff controllable via MIDI CC
Fully analog singal path with VCO, VCF and VCA
VCO switchable between sawtooth and square waveforms
4-Pole lowpass filter with resonance
VCF envelope intensity and envelope decay adjustable
Adjustable Accent and overdrive
16-Step sequencer with 250 memory locations for patterns
16-Voice Poly Chain of up to 16 units
Audio input for sound processing of external sources: 3.5 mm jack
Inputs for Filter FM and Filter CV (3.5mm jack)
Inputs for Accent, Slide, Sync and CV/Gate (3.5mm jack)
Outputs for Accent, Filter and CV/Gate (3.5mm jack)
Stereo headphones output (3.5mm jack)
Line out (6.3mm jack)
USB-MIDI and MIDI in/out
Dimensions (H x W x D): 56 x 305 x 165 mm
Weight. 0.8 kg
Colour: Black
Incl. 9 V DC power supply unit
