Behringer X32 Compact Stagebox t.Plus

Technical Data

• Manufactured by Behringer
• Released in 2013
• Average price : $3985
• Digital Mixer
• 16 XLR Mic/ line Inputs
• 8 Stereo FX Returns
• 16 Mix buses
• 6 Matrix buses with insert
• 6 Mute groups
• 8 DCA groups
• 8 XLR Outputs
• 6 AUX In: 6.3 mm Jack (optionally 2 via RCA)
• 6 AUX Out: 6.3 mm Jack (optionally 2 via RCA)
• AES/EBU Stereo digital output
• 2 Headphone outputs: 6.3 mm Jack
• Stereo monitor/ control room output with dim function
• 32 In/ 32 out USB audio interface
• 100 mm Motor fader
• 7" TFT colour display
• LCD Display per channel
• 4-Band full-parametric EQ per channel
• Adjustable delays in all channels
• Virtual effect rack with 8 FX slots
• Built-in stereo USB recorder
• Remote control via ethernet
• Compatible with the Behringer P-16 personal monitoring system
• Full MIDI implementation
• Dimensions (H x W x D): 21.3 x 63.1 x 51.2 cm
• Weight : 15.5kg
• Digital Stagebox
• With 16 Inputs and 8 Outputs
• AES50 network (Klark Teknik)
• Up to 100m of networking capability via CAT-5e cable (not included in delivery)
• 7-segment LED displays
• Direct P-16 Monitor port
• Dual ADAT outputs
• MIDI In/Output
• USB connector for system updates via PC
• Format: 19" / 2HE
• Mounting depth: 21 cm
• Distance of the metal handles to the front: 2,2 cm
• Flight Case
• Custom-made for Behringer X32 Compact
• Material: 7 mm plywood
• 30 x 30 mm Aluminium edges
• Foam padding
• 4 Medium spring-loaded butterfly latches
• 6 Folding handles
• Steel ball corners
• 12 cm cable duct at the rear
• External dimensions (W x D x H): 70.5 x 70.5 x 28.5 cm
• Weight : 13.2kg
• Weight with X32: Approximately 29 kg
• Colour: Phenol Brown
• Made in Germany
• CAT5e Cable
• Length: 30 m
• 2x Hirose RJ45 connectors with Neutrik NE8MC1
• SF/UTP
• Fully tourworthy
• Colour: Black
• Made in Germany
• CAT 5 Cable
• 2x Hirose RJ45 connectors with Neutrik NE8MC1
• Length: 0.5 m
• Tourworthy
• Colour: Black
• Made in Germany
