Bettermaker VSPE

Vacuum Stereo Passive Equaliser

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Bettermaker
Analogue passive equaliser with tube and transformer circuit
HEAT circuit for more saturation through tubes and transformer
Seamless DAW integration via plug-in for recall and automation
Stereo and dual mono modes as well as digital high-pass and low-pass filters available via plug-in
Maximum input level: +24 dBu
Maximum output level: +22 dBu
Max. low frequency boost: 15 dB (at 100 Hz)
Max. low frequency attenuation: 16 dB (at 100 Hz)
Max. high frequency boost: 18 dB
Low boost/cut frequencies: 20, 30, 60, 100 Hz
High boost frequencies: 3, 4, 5, 6, 8, 10, 12, 16, 20, 28,000 Hz
High cut: 5, 10, 20,000 Hz
Dimensions (W × H × D): 482 × 88 × 140 mm
Weight : 2.7kg
