Blackmagic Design ATEM 2 M/E Production Studio 4

Technical Data

• Manufactured by Blackmagic Design
• Released in 2020
• Average price : $5974
• 4 Upstream keyers for chroma, linear and luma keys
• 2 Downstream keyers
• 4 Chroma keyers
• 7 Linear/luma keyers
• 1 Transition keyer (Stinger/DVE)
• 1 DVE
• 13 levels
• 8 Pattern generators
• 2 Colour generators
• 1 DVE with 3D outlines and shadow casting
• Software or optional hardware control panel
• Multi View Monitoring: 2 x 10 views
• Integrated LCD monitor for video and 42 LED buttons for AUX switching
• Power supply: 2 integrated 100 - 240 V AC power supplies
• Power consumption: 150 W
• Dimensions : 482mm x 90 (2U)mm x 235mm
• Weight : 4.1kg
• Free included operating software ATEM Software Control for Mac 10.12 Sierra, Mac High Sierra 10.13 or higher and Windows 8.1 64-bit or Windows 10 64-bit
• 21 Video inputs (20 active)
• 16 Video outputs
• 6 Aux outputs
• SDI rates: 270 Mbit, 1.5 G, 3 G, 6 G
• 2 XLR audio inputs
• 2 RCA audio outputs
• 2 connections for XLR programme and 2 for XLR monitors
• Time code connections: 1 XLR input and 1 XLR output
• Reference input: Tri-Sync or Black Burst
• Video inputs with resync: on all 20 inputs
• SDI video inputs: 20 x 10 bit
• SD/HD/Ultra HD 4K switchable (2 embedded audio channels)
• 1 HDMI type A video input, switchable between 10 bit SD/HD/Ultra HD 4K (2 embedded audio channels)
• SDI audio outputs: 2 channels embedded in the SDI output on all outputs
• SDI programme outputs: 3 x 10-bit SD/HD/Ultra HD 4K, switchable
• HDMI programme outputs: 1 HDMI type A 10 bit SD/HD/Ultra HD 4K, switchable
• Down-converted SDI programme outputs: 1 x 10 bit (Ultra HD 4K to HD)
• SDI preview outputs: 1 x 10 bit SD/HD/Ultra HD 4K, switchable
• 2 Multi Views
• 2 SDI multiview outputs
• 2 HDMI multiview outputs
• Console connection: Ethernet supports 10/100/1000 BaseT (allows direct connection between console and housing or via network)
• Tally output: optional via Ethernet connection to Blackmagic Design GPI and Tally Interface (not included)
• Computer interface: 1 USB 2.0 port
