Blackmagic Design ATEM Mini Pro ISO
Live Mixer with Four Scalable HDMI Inputs
Latest User Reviews
Top AIO Video Mixer
It's a very good aio video mixer. Audio management could be better but we must remember it's an aio product.
For dimensions and price it's a great product.
Overall good
Latency can be a bit of an issue
Everything you need for multicam/multi source streaming
I got this to live-stream a film festival. there were two video sources and a live cam with green screen. It was a real rush job - we had a couple of hours to set up and learn how to use the ATEM. The hardest was setting the chroma-key for the green screen. We were also streaming directly from the ATEM to Vimeo. Basically we used almost all the features of the ATEM. I was totally impressed with the functionality an how intuitive it is to use. Many pro broadcast features but for a consumer price. 100% recommended!
Best low-budget live mixer with constantly improving service with new updates. You can do almost anything you want. The feature of automatic resolution scaling is priceless!
Best switcher!
Really happy with this switcher. Small, compact with so many high end features. Love the ISO recordings, so handy to have. Only issue is its lack of outputs. Streaming bridge required for program output. Possible with the HDMI Output but then you loose the multi-view. All these issues are fixed with the Atem Extreme. But this is still a great switcher!
Fantastic bit of kit
Used this in "anger" for the first time yesterday - absolutely love it! the ability to have a surface, ISO recording and switching built in to a unit at this price point is phenomenal!
It does get a little warm but seemed not to affect its use.
so very clever
You can't beat these, they're brilliant
Technical Data
- Manufactured by Blackmagic Design
- Released in 2020
- Average price : $650
- With USB webcam output, audio mixer with EQ and dynamics, 2D DVE, transitions, green screen chromakeyer, capacity for 20 stills for titles and much more
- In addition to the basic functionality, allows recordings on USB drives in H.264 format
- Integrated hardware streaming engine for YouTube Live, Facebook, Twitch and others
- Multiviewer for viewing all cameras on one monitor
- Can also record five streams including all signal inputs as clean feeds for editing
- Generates a DaVinci project file for fast cutting and creates a new link to the Blackmagic RAW file for Ultra HD finishing
- Video inputs: 4x HDMI type A 10-bit HD (switchable, 2 embedded audio channels)
- Video outputs: 2
- AUX outputs: 1
- Audio inputs: 2x 3.5 mm stereo mini jacks
- No audio outputs, only embedded audio
- Resync on all four HDMI inputs
- Frame rate and format converter on all 4 HDMI inputs
- HDMI program outputs: 1
- Ethernet: Supports 10/100/1000 BaseT for live streaming, software control, software updates and connecting a control panel to the mixer directly or via network
- Computer interface: 1x USB port type C 3.1 1st generation for recording on external hard drives as well as for webcam output, software control, software updates and for connecting a control panel
- HD video input standards: 720p/50; 720p/59,94; 720p/60; 1080p/23,98; 1080p/24; 1080p/25; 1080p/29,97; 1080p/30; 1080p/50; 1080p/59,94; 1080p/60;1080i/50; 1080i/59,94; 1080i/60
- HD video output standards: 1080p/23,98; 1080p/24; 1080p/25; 1080p/29,97; 1080p/30; 1080p/50; 1080p/59,94; 1080p/60
- Video standards for streaming: 1080p/23,98; 1080p/24; 1080p/25; 1080p/29,97; 1080p/30; 1080p/50; 1080p/59,94; 1080p/60
- Video sampling rate: 4:2:2 YUV
- Colour accuracy: 10-bit
- Colour spaces: Rec 709
- HDMI input resolution from computers: 1280 x 720p 50 Hz, 59.94 Hz and 60 Hz; 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 Hz; 1920 x 1080i 50, 59.94 and 60 Hz
- Colour space conversion: Hardware-based in real time
- Upstream keyers: 1
- Downstream keyers: 1
- Advanced Chroma keyers: 1
- Linear / Luma keyers: 2
- Transition keyer: DVE only
- Total number of levels: 5
- Pattern Generators: 1
- Colour Generators: 2
- DVE with borders and shadows: 1
- Audio mixer: 6 Inputs with 2 channel mixers each
- Channel-by-channel preset for switching audio-follows-video on or off, as well as separate gain control for each channel
- Level and peak level measurement
- Fairlight audio features: Compressor, gate, limiter, parametric 6-band EQ, main gain control
- Analogue input: Unbalanced stereo
- Analogue input delay: Up to 8 frames
- Input impedance: 1.8 k
- Maximum input level: +6 dBV
- Direct streaming: Supports direct live streaming via Ethernet using Real Time Messaging Protocol (RTMP)
- Includes ATEM software control panel for Mac Mojave 10.14, Mac Catalina 10.15 or higher and for Windows 10 only in 64 bit
- Power consumption: 36 W
- Dimensions: 238 x 104 x 35 mm
- Weight : 550g
- Includes external 12V DC power adapter with plug adapters for all countries
