Blackmagic Design MC BiDirect. SDI/HDMI 12G wPSU

Name: MC BiDirect. SDI/HDMI 12G wPSU
Brand: Blackmagic Design
Price: 250 USD
Rating: 100 (2 reviews)

Compact Converter Including Power Supply

100/100

based on 2 reviews.

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Latest User Reviews

2 years ago

All is fine, except no options for mounting on other equipment.

4 years ago

Does exactly what it says on the tin, with minimal fuss.

Manufactured by Blackmagic Design
Released in 2021
Average price : $250
Simultaneously converts SDI to HDMI and HDMI to SDI in all SD, HD and Ultra HD formats up to 2160p/60
Conversion in both directions can be done in different SD, HD and Ultra HD video standards
Equipped with full-size HDMI connectors and professional 12G-SDI connectors
Works in all NTSC, PAL, 720p, 1080p, 1080PsF, 1080i and 2160p rates, including 4K DCI in 24/47,95/48
Powered via USB-C socket
1 SDI video input
SDI video outputs: automatic adjustment to HDMI video input
1 HDMI 2.0 video input
1 Type A HDMI 2.0 video output
SDI rates: 270 Mbps, 1.5 G, 3 G, 6 G, 12 G
Multirate support: Automatic detection of SD, HD, 2K, Ultra HD and 4K
Updates, configurations and power supply: USB Type C
Reclocking
Camera Control: bidirectional signal conversion supports Blackmagic Camera Control and Tally
Compatible operating systems: Mac Catalina 10.15, Mac Big Sur 11.1 or higher / Windows 10, 64 bit
Power consumption: max. 5 W
Operating voltage range: 4.40 - 5.25 V DC
Dimensions: 81 x 59 x 25 mm
Weight : 174g
Includes +5V universal power supply with plug adapters for most countries
