Blackmagic Design Mini Converter SDI - Audio

Technical Data

• Manufactured by Blackmagic Design
• Released in 2020
• Average price : $274
• To extract audio from any SDI sources in the formats SD and HD up to 1080p / 60
• Audio signals are transmitted via jack sockets as symmetrical analog audio or AES / EBU audio to devices such as mixers, analog MAZs, audio monitors or similar. spent
• 1 x SD, HD or 3G-SDI video input
• 1 x ALT-SDI video input that is automatically switched to if the main input fails
• 1 x SDI loop-through output
• 4 x Channels of balanced analog audio or 8 channels of digital AES / EBU audio
• Redundant SDI inputs with automatic switchover if the main SDI input fails
• Multi-rate support: Automatic detection of SD, HD and 3G-SDI
• With reclocking
• Power supply via +12 V DC universal power supply with plug
• Adapters suitable for all countries (included in delivery)
• Power consumption: 5.52 W.
• Operating voltage range: 12 - 15 V DC
• Dimensions (WxHxD): 92.27 x 23 x 114.83 mm
• Weight : 215g
