Blackmagic Design DeckLink Mini Monitor 4K
PCI Express Playback Card
Latest User Reviews
3 years ago
Does What It Should
Does what it should. I have it installed in a OWC thunderbolt enclosure hooked up to my Mac Studio which feeds a LG OLED 48".
Works perfectly.
Has an SDI out too which can feed into a scopes unit or another monitor with an SDI in.
5 years ago
colorist standard
blackmagic quality, does its job perfectly, 4k hdr rec2020 works with resolve, premiere, avidmediacomposer, assimilate ... etc ....
Technical Data
- Manufactured by Blackmagic Design
- Released in 2020
- Average price : $243
- Low-profile PCI Express playback card with 6G-SDI and the latest HDMI 2.0a connectors
- For controlling all formats up to 2160p/30 from the computer
- SDI and HDMI outputs can be connected to any TV or monitor
- All video formats are automatically detected and switched accordingly
- HDR playback and metadata transfer via HDMI
- Blackmagic Desktop Video SDK for Mac OS, Windows and Linux lets you create your own customised playback solutions
- Physical installation: PCI Express 4 Lane Generation 2, compatible with 4-, 8- and 16-lane PCI Express slots on Mac OS, Windows and Linux. Mac OS systems require a Mac Pro computer with PCI Express slots. Please see the support pages for full system requirements.
- Software included: Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic drivers on Mac OS and Windows, Media Express, Blackmagic Desktop Video Utility and Blackmagic drivers on Linux.
- SDI video outputs: 1 connection for 10-bit SD/HD/Ultra HD, switchable.
- SDI audio outputs: 16 channels embedded in SD, HD, Ultra HD
- HDMI video outputs: 1 HDMI 2.0a connector
- HDMI audio outputs: 8 channels embedded in SD, HD, Ultra HD
- Computer interface: PCI Express with 4 lanes Generation 2, compatible with 4-, 8- and 16-lane PCI Express slots
