Blackmagic Design MultiView 16

Video Source Monitoring

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Blackmagic Design
Released in 2020
Average price : $2023
Allows monitoring of up to 16 SDI video sources with one Ultra HD monitor or TV (monitor / TV not included)
This results in twice the resolution per viewing window
Monitoring of SD, HD or Ultra HD SDI sources, in any combination and in any order
Full frame resynchronisation at each input
SDI neutrality: all SDI outputs automatically switch between standard definition, high definition or 6G SDI video
Reference input: Black Burst and Tri Sync for SD, HD and 4K
Multirate support: automatic detection of SD, HD or 6G-SDI
Simultaneous viewing of 4K, HD and SD video.
Updates: USB 2.0 high-speed interface (480 Mbps) or via Ethernet
Configuration: Via front panel LCD or via RJ45 Ethernet or USB 2.0 for firmware updates and IP address setting
Control: 16 keys for local control of the MultiView 16, five keys and scroll wheel for control of the LCD or RJ45 Ethernet
Compatible with operating systems: Mac 10.11 El Capitan, Mac 10.12 Sierra or higher, Windows 8.1 and 10
Input voltage: 90 -240 V AC (IEC power cable not included)
Power consumption: 45 W
Dimensions : 482mm x 44 (1U)mm x 153mm
Weight : 2.3kg
SDI video inputs: 16x 10-bit SD-SDI, HD-SDI and 6G-SDI
SDI video outputs: 16x 10 bit SD-SDI, HD-SDI and 6G-SDI
SDI rates: 270 MBit /1.5 G /3 G / 6 G
SDI video outputs for multiple display: 2x 10-bit HD-SDI, 2x 10-bit 6G-SDI
HDMI video outputs for multiple display: 1 HDMI type A socket (output supports EDID data of the monitor)
