Blackmagic Design MultiView 4

Multi-View Router

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Blackmagic Design
Released in 2020
Average price : $698
For image monitoring of four completely separate SDI video sources on a single display
Four 6G SDI inputs with full resynchronisation allow monitoring of SD, HD and Ultra HD video formats and frame rates in any combination and completely simultaneously
Can output content to 1080HD and 2160p displays, i.e. it can be connected to common HD and Ultra HD televisions
Various overlays such as audio level meters, custom labels and more can be displayed in each view
SDI video input: 4x 10-bit SD-SDI, HD-SDI and 6G-SDI
SDI video output with loop-through: 4x 10-bit SD-SDI, HD-SDI and 6G-SDI
SDI video output for multiple display: 1x 10-bit HD-SDI
HDMI video outputs for multiple display: 1x HDMI type A supports monitor EDID data
Reclocking
90 - 240 V AC input voltage or Power Over Ethernet (48 V DC via PoE)
Power consumption: approx. 16 W
Dimensions : 14mm x 4.42mm x 17 cm
Weight : approx. 580g
