Blackmagic Design Smart Videohub 12x12

Name: Smart Videohub 12x12
Brand: Blackmagic Design
Price: 1682 USD
Rating: 100 (1 reviews)

6G-SDI Router 12x12

100/100

based on 1 review.

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Latest User Reviews

4 years ago

Excellent device. Does exactly what we need it to. Very user friendly and easy to set up. Does what it says on the tin. Happy out!

Manufactured by Blackmagic Design
Released in 2020
Average price : $1682
Supports any SD, HD or Ultra HD SDI formats on the same router
Provides 12 inputs and 12 outputs, plus connections for video reference and redundant power supply
LC display for monitoring and showing signal path identifiers
Signal distribution can be selected and executed directly with the push of a button or with the rotary control
Ethernet interface for remote control and a fully customisable software development kit for Mac and Windows
SDI video inputs: 12 x 10-bit SD-SDI, HD-SDI and 6G-SDI
SDI video outputs: 12 x 10-bit SD-SDI, HD-SDI and 6G-SDI
SDI rates: 270 Mbit, 1.5 G, 3 G, 6 G
SDI neutrality: On all SDI outputs
Reference input: For tri-sync or blackburst signals
Control panel connection: Ethernet
Serial control port: RJ-6 RS-422
Multirate support: automatic detection of SD, HD or 6G SDI (simultaneous routing of 4K, HD and SD video)
Updates: USB
Front panel router control: 12 buttons for local control of video hub / 6 buttons and knobs for control of LCD display or RJ45 Ethernet
Supported operating systems: Mac Mojave 10.14, Mac Catalina 10.15 or higher / Windows 8.1 and 10
Power supply: 90 - 240 V AC input voltage (IEC power cable not included)
Dimensions : 482mm x 44 (1U)mm x 160mm
Weight : 1.88kg
