Blackmagic Design SmartScope Duo 4K 2

Monitor Bridge

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Blackmagic Design
Released in 2020
Average price : $1250
Two 8" 3U-sized LCDs for monitoring SDI/HD-SDI/3G-SDI and 6G-SDI with integrated scopes for technical waveform monitoring
Choice of waveform, vectorscope, RGB parade, YUV parade, histogram and audio phase level displays
Both monitors work independently and can display any combination of scopes or image displays
SDI video inputs: automatically switches between SD, HD and 6G SDI signals
Reclocked loop-through output
SDI video outputs: 1 x 10-bit loop-through SD/HD and 6G-SDI, switchable
SDI audio inputs: 16 channels embedded SD, HD and UHD
SDI audio outputs: 16 channels embedded in SD, HD and UHD
Multi-rate support
Standard Definition SDI, High Definition SDI and 3G-SDI
Tally: 9-pin SUB-D connector
19" Rack compatible
Dimensions : 482mm x 133mm x 32mm
Weight : 1.53kg
