Blackmagic Design Teranex Mini 12G-SDI -Quad SDI

Technical Data

• Manufactured by Blackmagic Design
• Released in 2021
• Average price : $698
• Enables connection of 12G-SDI Ultra HD equipment to Quad Link
• Ultra HD equipment
• Distributes Ultra HD-SDI signals to four separate HD-SDI outputs
• 12G-SDI loop-through
• Supports both Level A and Level B 3G-SDI equipment
• SDI video inputs: 1 x 12G-SDI SD/HD/2K/4K auto-switching
• SDI video outputs: 4 x 3G-SDI and 1 x 12G-SDI loop-through output
• Embedded audio support: 16 channels
• Multi-rate support: Automatic switching between SD/HD/2K and 4K
• Updates and configuration: USB or Ethernet
• SDI video connections are switchable between Standard Definition
• High Definition Level A and Level B 3G-SDI
• 6G-SDI and 12G-SDI
• SDI video sampling frequency: 4:2:2 and 4:4:4
• SDI colour space: YUV and RGB
• Power: 16 W
• Power supply: AC power supply with IEC C14 connector
• 100-240 volt AC input voltage
• PoE+
• Dimensions (L x W x H): 140 x 170 x 44 mm
• Weight : 580g
