Blackmagic Design Teranex Mini HDMI-Optical 12G

Converter from HDMI to 12G Fibre and 12G-SDI

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Blackmagic Design
Released in 2020
Average price : $698
Works with all video formats including SD, HD, 6G and 12G-SDI
With up-converter for converting HD to Ultra HD
Embeds balanced analogue or AES/EBU, time code signals and SDI
Ideal for converting signals from HDMI consumer cameras to SDI or for providing computers with HDMI connections with extra SDI outputs
Ethernet interface for remote administration and control
Support for embedded audio: 16 Channels
Multi-rate support: Automatically switch between SD/HD/2K and 4K
Dimensions : 140mm x 44mm x 170mm
Weight : 580g
SDI video inputs: Optional 3G/6G/12G fibre-optic SFP input
SDI video output: 1 x 12G-SDI
HDMI video input: 1 HDMI 2.0 Type A connector with support for 2160p/60
Fibre-optic connection (optional): Optional 3G/6G/12G fibre-optic SFP output
Fibre-optic video outputs: Automatically adjusts SD, HD, and 12G-SDI HDMI video input
Analogue audio inputs: 2 Channels of balanced analogue audio via XLR connectors
Right XLR socket configurable for time code input
Digital audio inputs: 4 Channels of professional balanced 110O digital audio via XLR connectors
Right XLR socket configurable for time code input
