Blackmagic Design Teranex Mini SDI - HDMI 12G

12G-SDI to HDMI Converter

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Blackmagic Design
Released in 2020
Average price : $541
Supports all video formats including SD, HD, 6G and 12G-SDI
Integrated down-converter for working with HDMI monitors, converts signals into the optimal format supported by this
Removes audio signals from SDI and embeds them in balanced analogue or AES/EBU formats and timecode output
Instant lock on HDMI output
33-Point LUT
Perfect for using with HDMI TVs as SDI broadcast monitors and for connecting video projectors
Reclocking
Multi-rate support: 270 MH, 1.5G, 3G, 6G and 12G
SDI video inputs: 1x 12G-SDI SD/HD/2K/4K automatically switching
SDI video outputs: 1x 12G-SDI loop-through output
HDMI video outputs: 1x HDMI 2.0 Type A connector with support for 2160p/60
Analogue audio outputs: 2 Channels of balanced analogue audio via XLR sockets (right XLR socket configurable for time code output)
Digital audio outputs: 4 Channels of balanced 110 O digital audio via XLR sockets (right XLR socket configurable for time code output)
Support for embedded audio: 8 Channels
Updates and configuration: USB or Ethernet
PoE+ capable
