Blackmagic Design Web Presenter HD
Complete Streaming Solution
Latest User Reviews
Good piece of equipment
Excellent piece of gear to give the older ATEM line of switchers the streaming capability of the ATEM Minis.
I bought this mainly with the idea of doing the same as the LiveUSolo on a budget and allowing a camera operator to stream back to studio to a ATEM Streaming Bridge with minimal training required. But it surpassed this and I've used it to stream beside by ATEM Mini simultaneously to other platforms, often with better results.
The one advantage over the ATEM Mini is you can scale and change your streaming setting without pausing the stream. Plus its Monitor Output has excellent streaming information.
One niggle I have found is that it occasionally refuses to stream despite pressing the On Air button or in software and requires a quick reboot whereupon it works flawlessly.
Technical Data
- Manufactured by Blackmagic Design
- Released in 2021
- Average price : $665
- Hardware streaming engine to stream directly to YouTube, Facebook, Twitter and other platforms via Ethernet
- Can stream to the Internet via Ethernet or use mobile data via a connected 5G or 4G mobile phone
- As the built-in USB ports act like a webcam, a computer can be connected to use any video software
- Monitoring output for video image, audio level meter, trend graphs, etc.
- Power supply: 1 integrated AC power supply for 100-240 V (IEC power cable not included) or 1x +12 V DC 4-pin XLR connector
- Power consumption: 21 W
- Dimensions: 140 x 175.5 x 44 mm (1/3 rack width)
- SDI video inputs: 1
- SDI video outputs: 1 loop-through output, 1 monitoring output
- SDI rates: 1.5 G, 3 G, 6 G, 12 G
- HDMI video outputs: 1 monitoring output
- Webcam output: 1 USB type C
- Ethernet: supports 10/100/1000BaseT for live streaming, software control and software updates
- HD video input standards:720p/50; 720p/59.94; 720p/60; 1080p/23.98; 1080p/24; 1080p/25; 1080p/29.97; 1080p/30; 1080p/50; 1080p/59.94; 1080p/60; 1080PsF/23.98; 1080PsF/24; 1080PsF/25; 1080PsF/29.97; 1080PsF/30;1080p/50; 1080p/59.94; 1080p/60.
- Ultra HD standards for video inputs: 2160p/23.98; 2160p/24; 2160p/25; 2160p/29.97; 2160p/30; 2160p/50; 2160p/59.94; 2160p/60
- Colour space for video inputs: Rec.601, Rec.709, Rec.2020
- 3G-SDI: Automatic detection of SMPTE level A or B on SDI input
- Video standards for SDI and HDMI monitoring outputs: 1080p/50, 1080p/59.94, 1080p/60
- Video standards for streaming: 720p/25; 720p/30; 720p/50; 720p/60; 1080p/23.98; 1080p/24; 1080p/25; 1080p/29.97; 1080p/30; 1080p/50; 1080p/59.94; 1080p/60
- Direct streaming: The Blackmagic Web Presenter HD supports direct live streaming via Ethernet using Real Time Messaging Protocol (RTMP).
- Closed captions: the Web Presenter HD supports embedding closed captions into your RTMP live stream in CEA-608 and CEA-708 standards
- Control panel/panel: front panel with 2.2-inch colour display for video preview, audio level meter and status indicator
- Device control: front USB-C port or Ethernet
- Compatible services and software: YouTube Live, Facebook Live, Twitter, Twitch, Skype, Open Broadcaster and Wowza Streaming Engine
