Bose DesignMax DM3C black

Technical Data

• Manufactured by Bose
• Released in 2020
• Average price : $518
• Equipped with: 1x 3.25" woofer and 1x 0.75" driver
• Easy installation thanks to QuickHold mounting arms
• Removable logos
• Euroblock connections
• FrontAccess for connection and troubleshooting from the front
• Frequency response (-10 dB): 75 - 20,000 Hz
• Dispersion angle: 170° Conical
• Power: 25 W RMS / 100 W peak
• Sensitivity (SPL / 1W @ 1m): 83 dB
• Max. sound pressure level (1m): 97 dB / 103 dB peak
• Transformer outlets 70 V: 3 / 6 / 12 / 25 W / bypass
• Transformer outlets 100 V: 6 / 12 / 25 W / bypass
• Impedance: 8 Ohm
• Dimensions (front grille diameter x depth): 255 x 154 mm
• Installation container dimensions (diameter x depth): 203 x 144 mm
• Ceiling cutout (diameter): 208 mm
• Maximum ceiling thickness: 39 mm
• Weight of each ceiling speaker: 2.7 kg
• Colour: Black
