Bose DesignMax DM5C white

Technical Data

• Manufactured by Bose
• Released in 2020
• Average price : $701
• Equipped with: 5.25" Woofer and 1" tweeter
• Easy installation thanks to QuickHold mounting arms
• Removable logos
• Euroblock connections
• FrontAccess for connection and troubleshooting from the front
• Frequency response (-10 dB): 65 - 20,000 Hz
• Dispersion angle: 160° Conical
• Power: 50 W RMS / 200 W peak
• Sensitivity (SPL / 1W @ 1m): 86 dB
• Max. sound pressure level (1m): 103 dB / 109 dB peak
• Transformer outlets 70 V: 3/6/12/25/50 W / bypass
• Transformer outlets 100 V: 6/12/25/50 W / bypass
• Impedance: 8 Ohm
• Dimensions (front grille diameter x depth): 304 x 206 mm
• Installation container dimensions (diameter x depth): 244 x 192 mm
• Ceiling cutout (diameter): 250 mm
• Maximum ceiling thickness: 48 mm
• Weight of each ceiling speaker: 4.45 kg
• Colour: White
