Bose DesignMax DM8C-SUB black

Technical Data

• Manufactured by Bose
• Released in 2020
• Average price : $627
• Equipped with: 8" Woofer
• Easy installation thanks to QuickHold mounting arms
• Removable logos
• Euroblock connections
• FrontAccess for connection and troubleshooting from the front
• Frequency response (-10 dB): 38 - 155 Hz
• Dispersion angle: Omnidirectional radiator below 200 Hz
• Power: 150 W RMS / 600 W peak
• Sensitivity (SPL / 1W @ 1m): 89 dB
• Max. sound pressure level (1m): 111 dB / 117 dB peak
• Transformer outlets 70 V: 20/40/80/150 W / bypass
• Transformer outlets 100 V: 40 / 80 / 150 W / bypass
• Impedance: 8 Ohm
• Dimensions (front grille diameter x depth): 409 x 255 mm
• Installation container dimensions (diameter x depth): 342 x 241 mm
• Ceiling cutout (diameter): 349 mm
• Maximum ceiling thickness: 76 mm
• Weight of each ceiling speaker: 9.8 kg
• Colour: Black
