Botex DD-3-4U RJ45

1-in-3 DMX Splitter

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Botex
Released in 2020
Average price : $120
For 4 DMX universes
Powerful DMX splitter for stages and fixed installations
For use with Stairville RJ45 Rack Split, DMX Split Box and DMX Shuttle Snake
The optional split boxes combine four DMX lines onto one CAT5 cable
The DD-3-4U processes the signal of all four universes independently and outputs it again amplified to the three RJ45 outputs - this way all four DMX lines can be played out at three locations on stage or in the rig, again using one of the Stairville DMX split boxes
LEDs show the DMX signal for each DMX line.
Power LED
Flexible use due to mounting thread (M10) and the supplied rack kit (19" / 1U)
2 Units can be connected and mounted on one height unit (no additional parts required)
Power input and output: Power Twist
DMX input and output: RJ45
Lockable
Dimensions without rack kit (W x H x D): 170 x 44 x 170 mm
Weight : 1.1kg
