Botex SDC-24 DMX Desk Road Pack

Botex SDC-24 DMX Desk

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Botex
Released in 2019
Average price : $230
24-Channel DMX console for 19" rack installation
Ideal for testing DMX devices or for simple applications
24 High-quality channel faders
Two displays for displaying the outgoing channel values
Start address selectable via dip switch
The 3-pin XLR DMX input can link up to four consoles to control up to 96 channels
For 19" rack installation
DMX output: XLR 3-pin, current input: IEC
Integrated power supply
Power supply: 110 - 240 V AC ~ 50/60 Hz
Power consumption: 4 W
Dimensions : 482mm x 82mm x 125mm
Weight : 2.3kg
Includes additional 16 coloured fader caps
19" Case
Suitable for Stairville DMX Master, GLP Scan Operator, etc.
For permanent installation of the 19" Scan Operator
3 U Usable height
8.5 cm Installation depth
Material: 7 mm plywood
22 x 22 mm Aluminium edges
Adjustable, stepless rack rail
Small ball corners
2 Drawbolts
1 Suitcase handle
Rubber feet
External dimensions (W x H x D): 56.3 x 16.4 x 23.8 cm
Weight : 3.8kg
Colour: Phenol Brown
Made in Germany
