Cameo SB 6T RDM
6-Output DMX / RDM Splitter / Booster
Technical Data
- Manufactured by Cameo
- 6 Optically and electronically separated 3- and 5-pin XLR outputs
- Compact housing
- 3x M10 thread inserts for a variety of truss mounting options
- Power and DMX status indicators on the front and back
- DMX inputs: 2 (parallel)
- DMX inputs: XLR 3-pin / 5-pin male
- DMX Thru outputs: 2 (parallel)
- DMX Thru output: XLR 3-pin / 5-pin female
- DMX outputs: 6
- DMX output: XLR 3-pin / 5-pin female
- Operating voltage: 100 V AC - 240 V AC 50 - 60 Hz
- Power consumption: 10 W
- Power connection: Power Twist In / Output
- Dimensions : 185mm x 77mm x 170mm
- Weight : 1.3kg
