Cameo LUKE 700 RGB

Technical Data

• Manufactured by Cameo
• Released in 2015
• Average price : $677
• Professional show laser
• Graphic projection effects with crystal clear, razor sharp beams
• 3 mm beam diameter with a maximum of 2 mrad divergence
• Diode and DPSS lasers for red, green and blue
• Double layer construction
• Power supply and fan are separated from the optical components
• Low-noise fan ensures low operating temperatures
• High speed 30 kpps Galvos @ 8° ILDA
• 128 Presets
• ILDA interface with 25-pin D-sub connectors for computer control
• DMX control modes in 4- and 11-channel mode
• Adjustable microphone for sound control
• Operating as a master, slave and standalone
• Robust and lightweight aluminium housing
• Key switch to prevent unauthorized use
• Bright display with four buttons for manual operation
• Scan fail safety-system
• Total output: 700 mW
• Colour spectrum: RGB
• Wavelength(s): 650 nm, 532 nm, 447 nm
• Beam properties: approx. 3 mm/2 mrad divergence
• Laser sources: Laser Diode & DPSS
• Laser class: 4
• Scanner: High performance galvo scanner
• 30 kpps 8 degrees ILDA
• Scanning angle max: 60°
• Operating modes: ILDA, DMX-512, auto, sound control
• DMX Input: 3-pin XLR
• DMX output: 3-pin XLR
• ILDA input: 25-pin Sub-D male
• ILDA output: 25-pin Sub-D female
• DMX-Modus: 4-channel, 12-channel
• Controls: Mode, enter, value down, value up
• Display elements: LC-Display
• Power supply: AC100-240V / 50-60 Hz
• Power consumption: 75W
• Power connector: Neutrik PowerTwist
• Housing material: Aluminium
• Housing colour: Black
• Dimensions : 215mm x 157mm x 225mm (without bracket)
