Cameo SB 6 Dual DMX Splitter/Booster

Technical Data

• Manufactured by Cameo
• Released in 2016
• Average price : $170
• Format: 19" / 1U
• Professional solution for configuring DMX networks
• Enhances the DMX input signal and distributes it to 6 galvanically isolated outputs
• Is directly connected to the DMX console or DMX devices
• Bright LEDs display on the front panel the DMX and power status of the channels
• The outputs have been positioned on the rearside
• Switchable 120 ohm terminating resistor on the DMX THRU output and the power switch complete the equipment
• For easy access to all ports and for a 180 ° rotated mounting, the rack ears can be mounted on the rear panel
• DMX Inputs: 2 (parallel)
• DMX Input sockets: XLR 3-pin male, XLR 5-pin male
• DMX Thru outputs: 2 (parallel)
• DMX Thru output sockets: XLR 3-pin female, XLR 5-pin female
• DMX Outputs: 6
• DMX Output sockets: XLR 5-pin male, XLR 3-pin male
• Power on/off switch
• DMX Thru terminator
• Display elements: 6 x Power LEDs, 6 x Signal LEDs
• Power supply: IEC power connector
• Operating voltage: 230V AC, 50 Hz
• Power consumption: 15W
• Dimensions : 483mm x 44mm x 160mm
• Weight : 2.40kg
• Includes power cable
