CVW Crystal Video Panel Antenna

Technical Data

• Manufactured by CVW Crystal Video
• Released in 2021
• Average price : $894
• Increases range up to 2000 m
• Supports horizontal and vertical rotation
• Compatible with Pro series and Beamlink series
• Compatible with the following CVW video radios: Pro200
• Pro300 Plus, Pro800, Beamlink Duo, Beamlink Quad, Beamlink Ultimate
• Frequency range: 5.1 - 5.9 GHz
• Gain: 16 +/- 1dBi
• Horizontal lobe width: 45° +/- 8°
• Vertical lobe width: 25° +/- 3°
• Resistance: 50 Ohm
• Antenna ports: 5 x N type female
• Rotation angle (vertical): -30° ~ +45°
• Battery mount: V-mount
• Tolerance range for humidity (in operation): <= 95%.
• Tolerance range for temperature (in operation): -40° ~ 60°
• Protection class: IPX1
• Dimensions: 450 x 200 x 25 mm (antenna without stand)
• Weight : 6kg
• Material: Steel
• Range with Pro series and Beamlink series up to 2000 m
• Included: 1 x antenna, 1 x stand and 1 x connection cable 40 cm
