Dynacord Xa2 Pro

Technical Data

• Manufactured by Dynacord
• Released in 2021
• Average price : $22493
• Passive midrange and tweeter
• Speaker configuration: 12" ND 12 A midrange driver and 2.4" ND 6 tweeter driver
• 80° x 40° constant directivity horn
• Power handling: 350 Watt (RMS)
• Maximum output level: 106 dB (1W / 1 m)
• Frequency range: 120 - 19.000 Hz
• Impedance: 8 Ohm
• Cabinet construction
• Coaxial arrangement
• For medium long distances
• Connectors: 2 x Neutrik SpeakOn NL4 In and Thru
• Cabinet made of 15 mm birch plywood
• 4 Castors
• 2 Handles
• Dimensions: 594 x 601 x 808 mm
• Weight : 49.5kg
• Colour: Black
• Passive Bass Speaker
• Loudspeaker configuration: KElectro-Voice EVX 180B 18" woofer
• Planar waveguide bass horn
• Power handling: 600 Watt (RMS)
• Maximum level: 101 dB (1W / 1 m)
• Impedance: 8 Ohm
• Frequency range: 30 - 150 Hz
• Connectors: 2 x Neutrik SpeakOn NL4 In and Thru
• 15 mm Birch plywood cabinet
• 4 Casters
• 6 Handles
• Dimensions: 610 x 905 x 814 mm
• Weight : 60.5kg
• Colour: Black
• Live Performance DSP Amplifier
• 2-Ohm stability
• Intuitive system control software for easy setup and control
• Balanced XLR in / out
• Speaker Twist connectors
• Dimensions : 483mm x 88mm x 462.4mm
• Weight : 18.2kg
• 2 Ohm: 3200 W
• 2.7 Ohm: 2700 W
• 4 Ohm: 1800 W
• 8 Ohm: 950 W
• 2.7 Ohm: 2500 W
• 4 Ohm: 1700 W
• 8 Ohm: 900 W
• Bridged: 4 Ohm: 6000 W
• Bridged 8 Ohm: 3400 W
