Enttec DIN Ethergate

Ethernet-to-DMX Converter

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Enttec
Released in 2022
Average price : $257
For connecting physical DMX devices to an Ethernet network infrastructure
Two universes for bidirectional eDMX-to-DMX conversion with Art RDM support
Installer-friendly features for quick installation and configuration, all managed via the user interface
Contained in a compact and electrically isolated 4-DIN module with wide form factor
Two bidirectional DMX/ E1.20 RDM ports with optional termination and RDM support
IEEE 802. 3af PoE (Power over Ethernet) or DC 7-24v input
Surface or TS35 DIN rail mounting
Support for Art-Net 4, sACN and ESP to DMX conversion
Support for DMX -> Art-Net (broadcast or unicast) / DMX -> ESP (broadcast or unicast) / DMX -> sACN (multicast or unicast)
HTP/LTP merge support for up to 2 DMX sources
Pluggable terminals and built-in DMX termination
Surface or TS35 DIN rail mounting
10/100 Mbps network speed
'Current Port Buffer' allows display of live DMX values
Configurable refresh rate
DC input voltage: 7 - 24 V DC
Max. Power consumption: 7 W
Power over Ethernet: IEEE 802.3af
Protection class: IP20
Dimensions: 100.5 x 72.25 x 34 mm
Weight : 0.16kg
