Enttec DIN RDS4
DMX Splitter
Technical Data
- Manufactured by Enttec
- 1 DMX/RDM input
- 4 DMX/RDM outputs
- 1500 V opto-isolation between each DMX port to protect against stray voltages on the DMX line
- Front-facing LED status indicator to show current DMX/RDM traffic
- Supported protocols: DMX512-A and ANSI E1.20 RDM
- Surface or TS35 top-hat rail mounting
- Max. 512 channels
- Voltage input: 7 - 24 V DC
- Dimensions: 100.5 x 72.25 x 34 mm
- Weight : 100g
