ESI U22 XT

USB 2.0 audio interface

Image ESI U22 XT

Rating :

1
2
3
4
5

stars

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Latest User Reviews

2 years ago

Brilliant and simple. easy to use.

2 years ago

Perfect

What I expected is what I got. No surprises. Top for your money

2 years ago

Do the basics very well

Do the basics very well

7 years ago

Let down by its Windows driver

Despite its excellent ASIO driver (v1.2) that allows for the usage at almost imperceptible ~3ms latency in a relatively complex projects, constant glitches in non-ASIO programs (music and video players, YouTube in browsers) and intermittent loss of connectivity made me return this otherwise great little device. Its footprint is perfect, main outs are loud and clear as is the headphone amp (much better than on my old Line6 UX2) driving my AKG K240, but knowing very well how long it can take for these companies to release driver updates that would fix such glaring issues (if they release them at all), I will have to look elsewhere for an upgrade.

8 years ago

Good sound quality, marred by the software and ergonomics

I bought this so I could use my PC as a recording studio. Out of the box, it worked well but when I downloaded the official drivers it became very flakey - every few minutes it would die and I'd have to unplug it and plug it in again to get it back. Deleting the drivers lost the ASIO capability, but at least it works reliably. The drivers referred to 4 inputs (1/2, 3/4) but, in fact, it has two inputs - there is another pair on the back, but they are accessed with a push button. Unfortunately, that's also on the back so it's quite awkward to switch over to using the rear inputs. Sound quality is really good - big step up over the PC's built in sound card.

Read all reviews >>

Technical Data

  • Manufactured by ESI
  • Released in 2016
  • Average price : $77
  • With 2 inputs and 2 outputs
  • Max. 24-bit / 96 kHz
  • Line, instrument and microphone input
  • Microphone preamp with + 48V phantom power
  • Line output with master volume control
  • Adjustable headphone output
  • Power supply via USB
  • Line input with RCA connector
  • Line output with balanced 6.3 mm jack connections
  • Headphone output 6.3 mm jack connection
  • A / D converter with 102 dB (a) dynamic range
  • D / A converter with 108 dB (a) dynamic range
  • Input and output monitoring can be controlled via the front panel
  • Master volume control on front panel
  • Supports Windows Vista / 7/8 / 8.1 and 10 with ASIO 2.0, MME
  • WDM and DirectSound incl. DirectWIRE support
  • Supports Mac OS X (10.7 and higher) via Apple's native CoreAudio USB audio drivers (no driver installation required, Mac Control Panel available)
  • Dimensions: 175 x 120 x 45 mm
  • Includes Deckadance LE license (from Image-Line Software) and Bitwig 8-track digital audio workstation software license
