Eurolite DMX Split/Boost 8 PRO 3-Pin

Technical Data

• Manufactured by Eurolite
• 2In/8Out with DMX monitoring in real time
• DMX modes: LTP, HTP, Merge or Backup
• Each DMX output with independent driver and status display
• Controllable via RDM
• Multicolour OLED display
• Power supply input and output for easy daisy chaining of up to 8 devices
• Original SEETRONIC plug connection installed
• Rack installation: 19" / 1 U - Installation depth: 48.3 cm
• Low-noise operation
• Power supply: 100-240 V AC, 50/60 Hz
• Power consumption: 5 W
• Protection class: IP20
• Power connection: Power Twist In / Out
• DMX connection: 2 x XLR
• Dimensions : 48.3mm x 16mm x 4.4 cm
• Weight : 2.23kg
• Includes power cable (1.45 m / 3 x 1.0 mm² H05VV-F) and operating instructions
