Frap Tools Fumana

Filter Module

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Frap Tools
Released in 2018
Average price : $1072
Dual 16 Band Spectral Editor Module
Fully analog, voltage controllable dual filter bank
Consisting of an array of 16 independent 48 dB/octave bandpass filters
Envelope followers per band for the first audio path - ideal for modulator signals
VCAs in the filter paths of the second channel to process carrier material
Different signals are on odd and even bands
Applicable to both main and modulator arrays
Direct outputs of each main filter
4 Voltage-controllable parameters to manage two independent functions for further spectral processing: Tilt and parametric scan
Unvoiced input for Vocoder effects
Width: 42 HP
Depth: 42 mm
Power requirements: +410 mA (+12 V) / -370 mA (-12 V)
