Gyraf Audio G14-S

Stereo Passive EQ

Image Gyraf Audio G14-S

Rating :

1
2
3
4
5

stars

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

  • Manufactured by Gyraf Audio
  • Released in 2022
  • Average price : $5420
  • Stereo equaliser with five bands
  • Each band with 11 switchable frequencies, continuously adjustable quality and individual boost/bypass/cut selection
  • Typical passive filter behaviour with rather broadband boosts and narrowband cuts
  • Relay bypass
  • Adjustable overall output level ( +3 to -5dB)
  • Switchable between tube and solid state topology
  • Tube amplification based on 6H23n (E88CC/6922) tubes
  • Balanced XLR inputs and outputs
  • Input impedance: approx. 5 kOhm
  • Output impedance; approx. 1K Ohm
  • Dimensions: 3 U, 19
  • Weight : 8kg
