Gyraf Audio G14-S

Stereo Passive EQ

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Gyraf Audio
Released in 2022
Average price : $5420
Stereo equaliser with five bands
Each band with 11 switchable frequencies, continuously adjustable quality and individual boost/bypass/cut selection
Typical passive filter behaviour with rather broadband boosts and narrowband cuts
Relay bypass
Adjustable overall output level ( +3 to -5dB)
Switchable between tube and solid state topology
Tube amplification based on 6H23n (E88CC/6922) tubes
Balanced XLR inputs and outputs
Input impedance: approx. 5 kOhm
Output impedance; approx. 1K Ohm
Dimensions: 3 U, 19
Weight : 8kg
