IMG Stageline DIB-102
2-Channel DI box
Latest User Reviews
Best Stereo DI
Has an awesome build quality. Does what it needs to do very well.
Great D.I. box
absolutely love these, can't be beaten for the price! great quality and durable enclosure.
Great functional DI boxes
I bought two of these for recording guitars/keyboards etc in my studio set up after faults occurred with my aging Behringer DI20. The IMG DIB-102 models are very user friendly, affordable, low noise DI boxes. The feed through output means I can easily record a signal directly from an instrument and then also through an amplifier. The duel inputs mean I can also record in stereo which is handy for keys etc. Having used various DI box brands over the years, I have found these DIB-102 to be my favorite so far. So far they have proved simple and reliable, everything I needed and expected.
Technical Data
- Manufactured by IMG Stageline
- Released in 2020
- Average price : $54
- For signal transmission from musical instruments to mixing console or amplifier
- Disturbances such as humming loops are avoided by transformer coupling
- Galvanically isolated inputs and outputs
- 3-Way attenuator switch (0/-20/-40 dB)
- Ground lift switch
- Instrument loop-through output
- Broadband balancing transformer
- Frequency range: 15-30000 Hz
- Input impedance: 50 kOhm
- Output impedance: 600 Ohm (symm.), 50 kOhm (asymm.)
- Gain: 0/-20/-40 dB
- Gear ratio: 10:1
- Inputs: 2 x 6.3 mm Jack, asymmetrical
- Outputs: 2 x 6.3 mm Jack, asymmetrical, 2 x parallel out XLR, balanced
- Metal housing
- Dimensions : 148mm x 50mm x 130mm
- Weight : 0.76kg
