Kramer 810

High-Performance Colour Bar Generator

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Kramer
Released in 2020
Average price : $568
For composite video and S-video (Y/C)
1000 Hz audio tone generator
Outputs two composite video signals and one S-Video colour bar signal as either NTSC or PAL
Simultaneously outputs a 1000 Hz audio tone signal
PAL/NTSC selector switch
Audio level adjustment (trim control)
75 dB video signal-to-noise ratio
Video outputs: 2x Comp.Video (75 % colour bar) with BNC socket
1 Vpp/75 Ohm and 1x S-Video (75 % colour bar) with 4-pin Hosiden socket, 1 Vpp/75 Ohm. Hosiden socket, 1 Vpp/75 Ohm (Y), 0.3 Vpp/75 Ohm (C)
Audio output: 1x stereo audio unbalanced 1 kHz, 4 dBu/74 Ohm with 3-pin screw terminal
Weight : 0.2kg
Dimensions: 120 x 71.5 x 24.4 mm
Includes power supply for 100-240 VAC and mounting bracket
