Kramer MV-6 Multiviewer

Technical Data

• Manufactured by Kramer
• High-performance multiviewer for 3G HD-SDI video signals
• Can display up to six inputs in any combination in SDI, HDMI and CV format, either in pre-programmed or customer-programmed image splitting
• Max. data rate: 3 GBit/s
• Kramer's re-clocking and equalisation technology: rebuilds the digital signal integrity for longer cable runs
• Multi-standard operation: SDI (SMPTE 259M)
• HD-SDI (SMPTE 292M) and 3G HD-SDI (SMPTE 424M)
• Re-clocked loop-through inputs
• Multi-format video outputs: 3G HD-SDI (SMPTE 424M)
• HDMI and CV with scaling and conversion of the frame rate and video standard
• Preview monitor integrated in the front panel: 4.3 inch (11 cm)
• Colour LCD (16:9) for displaying the output signal
• Text overlay: A text or symbol can be added to each window
• Each text has settings for text and background colour, alignment, size, etc.
• Front monitor adjuster: still image, size, position and four pre-programmed and two freely programmable layouts
• Front panel with two-line LCD, OSD, Ethernet and RS-232 (PC control software included)
• Inputs: 6x BNC socket for SDI, HD-SDI, 3G HD-SDI, each with loop-through output
• 1 HDMI output
• 1 BNC output socket for CV (for 720p @50 Hz and 1920p @50 Hz the output is PAL, for 720p @59.94/60 Hz and 1920p @59.94/60 Hz the output is NTSC)
• 1 BNC output socket for SDI, HD-SDI, 3G HD-SDI
• Max. output level: 800 mW at 75 Ohm
• Max. output level: 800 mW at 75 Ohm
• Max. data rate: 2.97 GBit/s
• Control: front panel, RS-232 and Ethernet
• Front monitor: 4.3" (11 cm) TFT colour LCD
• Power supply: 100 - 240 VAC, 50/60 Hz, 35 VA
• Dimensions: 43.6 (19") x 18.4 x 8.80 cm
• Height: 2 mm
• Weight : 3.1kg
• Includes power supply cable, rack mounting bracket, control software
