Kramer PT-571 HDMI Transmitter
Transmitter for HDMI Signals
Latest User Reviews
5 years ago
Works but only for shorter distances. When I have it run about 30-35 meters and connect iPhone on a projector it does not work; when I connect a PC, it works on the 30 meter distance but flickers.
Works perfectly with 10-15 metre runs.
Note that it needs all cabling and connections to be at least CAT6 and the shield has to be connected on everything.
Technical Data
- Manufactured by Kramer
- Released in 2014
- Average price : $226
- Twisted pair transmitter
- Converts an HDMI signal into a twisted pair signal
- Maximum data rate: 1.65 GBit/s
- HDMI 1.3
- HDCP compliant
- Power supply via external power supply unit 12 VDC 250 mA (transmitter and receiver combined)
- Dimensions : 6.2mm x 5.2mm x 2.4 cm
- Weight : Approximately 140g
- Optional: the PT-572+ converts the incoming twisted pair signal back into an HDMI signal
- When using BC-DGKat524 cable: up to 90 m at 1080i, up to 30 metres at 1080p
- When using C-DGKat623 cable: up to 100 metres at 1080i or at 1080p
