Kramer VM-50AN

Distribution Amplifier

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Kramer
Average price : $404
For balanced and unbalanced stereo audio signals
Balanced and unbalanced stereo audio input
10 Outputs
Signal-to-noise ratio: 84 dB
L and R level adjustable
Inputs: 1x stereo balanced +4 dBm/50 kOhm with detachable screw terminal connection and 1x stereo unbalanced 1 Vpp/50 kOhm with 3.5 mm jack socke
Outputs: 5x stereo balanced +4 dBm/50 Ohm with detachable screw terminal connection and 5x stereo unbalanced 1 Vpp/470 Ohm with 3.5 mm jack socket
Max. output level: >24 dBm
Bandwidth (-3dB): 40 kHz, fully wired
Signal-to-noise ratio: 84 dB, unweighted
Control: Level: 0.4 to 9.5 dB (for left and right channel)
Coupling input: AC
Coupling output: DC
Audio THD+noise: 0.002 % @ 1 kHz, balanced output
Audio 2nd harmonic: 0.022 % @ 1 kHz, balanced output
Power supply: 12 VDC, 200 mA
Dimensions: 16.3 x 12 x 4.4 cm
Weight : 0.6kg
