Laserworld CS-12.000RGB ShowNET

RGB Diode Laser System

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by Laserworld
Semi-professional pure RGB diode laser system with ShowNET mainboard
Guaranteed power: 12000 mW
Red: 3000 mW / 638 nm
Green: 3000 mW / 520 nm
Blue: 6000 mW / 450 nm
Beam data: approx. 5 mm / 1.2 mrad
Scanner: 30 kpps @ 8°, max. scan angle: 40°
Laser source: Diode
Laser class: 4
Operating modes: ILDA, DMX, LAN, ArtNet, ILDA streaming, integrated SD card, automatic mode, master-slave
Basic patterns: approx. 130 (levels, tunnels, grids, waves, etc.)
Effect gratings
ShowNET mainboard: Versatile control options: ILDA, professional DMX (two modes), professional Art-Net (two modes), stand-alone operation, ILDA streaming receiver, LAN (computer control, integrated DAC)
Create custom content, save it in the laser and play it back in different modes
protection class: IP54
Power supply: 85 V - 250 V AC, 50/60 Hz
Power consumption: 150 W
Dimensions: 285 x 180 x 190 mm
Weight : 7.7kg
Free laser show control software included
Includes power cable, operating instructions, interlock, key
