LD Systems ANNY 10 HHD B5

Technical Data

• Manufactured by LD Systems
• Equipped with: 10" woofer, 1" tweeter
• Integrated 6-channel mixer
• 3-Band Master EQ
• Foot switch input for hands-free effect control (reverb, delay)
• Priority/ducking mode to emphasise the microphone signal
• Built-in radio link with handheld microphone
• Frequency range: 584 - 608 MHz
• Bluetooth 5.0 and stereo streaming (TWS) possible with two ANNYs
• Power: 80 watts (RMS) / 160 watts (peak)
• Max. SPL: 118 dB (Peak)
• Frequency range: 45 - 20,000 Hz
• Dispersion angle (H x V): 90° x 50°
• 2 Mic/line combo inputs: XLR / 6.3 mm jack
• Stereo line 3.5 mm jack (RCA)
• Mix output: XLR
• USB-C port for charging smartphones and tablets
• Integrated lead-acid battery: 12V/5Ah
• Up to 20 hours runtime (ECO mode) / 5 hours (max. volume)
• Integrated holder for smartphones and tablets
• 35 mm Stand flange mount
• Integrated castors and trolley function
• Housing material: Plastic
• Dimensions : 361mm x 300mm x 566mm
• Weight : 18.4kg
• Includes 2 AA batteries
