LD Systems Curv 500 AVS

Compact and Modular Plug and Play Array System

If you own this item for a while and already published a review somewhere on the internet, you can publish it again here with a custom past date :

Technical Data

Manufactured by LD Systems
Released in 2015
Average price : $920
Discreet appearance for inconspicuous applications
DSP based multi-band limiter
Maximum level: 122 dB
Power: 380 Watt RMS
Frequency range: 47 - 20,000 Hz
Beam angle 110° horizontal x 10° vertival
10" Bass reflex subwoofer
Integrated Class D power amplifier
3 Handles
M20 Threads
4 Channel mixer with 4x XLR/jack combo input, 2x XLR male out
Integrated digital effects with 16 DFX presets
Adjustable for channel 1 and 2
Adjustable low and high for channel 1 and 2
Channel 3 and with integrated Bluetooth receiver and 3.5 mm stereo jack input
Adjustable sub level and main level
Expandable to 8 Array modules
M16 flange
Dimensions subwoofer: 325 x 383 x 491 mm
Dimensions Array satellites: 122 x 122 x 122 mm
Dimensions Smartlink adapter: 122 x 57 x 122 mm
Weight subwoofer: 16.5 kg
Weight Array satellites: 1.7 kg
Weight adapter: 0.6 kg
Colour: Black
Incl. 2 loudspeaker cables CURV 500 CABLE 2 (3 m) with speaker terminals and power cord
