Lindell Audio Track-Pack

Technical Data

• Manufactured by Lindell Audio
• Released in 2022
• Average price : $967
• Consisting of Lindell Audio 503 Power, 6X-500 and 7X-500
• Dimensions (L x W x H): 21 x 13 x 17cm
• Total weight: 3.7 kg
• Incl. panel, neoprene bag, mains cable and operating instructions
• 3-Slot rack for 500 modules
• 800 mA power per slot
• Internal universal power supply 90-250V
• Short-circuit and overload protection
• Lightweight aluminium housing
• 500 module
• Coupled transformers with sym. inputs and outputs
• Up to 65dB gain
• Passive Pultec-style EQ
• 3-Stage low EQ 30Hz, 60Hz and 100Hz (+/-10%)
• 3-Stage high EQ 6kHz, 10kHz and 16kHz (+/-10%)
• Selectable high boost bandwidth
• Phase switch
• 48V phantom power
• 5-LED VU meter
• 500 Module
• Parallel compression with crossfade control
• 3-Stage attack times
• 3-Stage release times
• 3-Stage high-pass sidechain filter: Off, 100Hz and 300Hz
• 3-Stage ratio: 4:1, 12:1 and 100:1 (all in)
• True hardware bypass
• Coupled transformer with balanced output
• 20-LED gain reduction meter
