Lindy 4K HDMI Over IP Extender RX

Technical Data

• Manufactured by Lindy
• Released in 2022
• Average price : $609
• Extends 4K HDMI or VGA, USB, IR and RS232 signals over a Gigabit IP network - includes video wall function
• Supports point-to-point installation up to 100 m and point-to-multipoint installation with a Gigabit switch (also for video walls)
• Extends USB 2.0, USB HID (for KVM functions), bidirectional analogue audio, bidirectional IR and RS232 signals
• AV interface: HDMI & VGA
• Console interface: USB
• Interface standard: HDMI 2.0, USB (HID) and USB 2.0
• Supported bandwidth: 10.2 Gbit/s
• Max. range: 100 m (point-to-point)
• Max. resolution: 3840x2160 60Hz 4:2:0 8Bit (VGA max 1920x1200 60Hz)
• HDCP support: HDCP 1.4 and 2.2
• Audio: Audio is supported via the HDMI signal and 2x analogue bidirectional (1x audio and 1x microphone)
• Separate audio ports: 2x 3.5 mm (jack), 1x SPDIF optical
• Transmission protocol: IP
• Transmission medium: Cat.6
• Video codec: Motion JPEG
• Latency: approx. 33 ms
• Special features: video wall function (up to 16x16 screens), VGA input & output support (max. resolution 1920x1440), bidirectional IR and serial RS232 extension
• Power supply: 5.5/2.1 mm DC socket
• Dimensions (WxDxH): 232 x 25 x 108 mm
• Weight : 0.67kg
• Receiver Console interface: HDMI (socket), 2x VGA (socket), 2x USB 2.0 type A (socket), 2x USB HID type A (socket), 2x 3.5mm audio (socket)
• Receiver extension port: RJ45 Gigabit Ethernet (PoE support)
• Bi-directional ports: 1 x DB9 (male) for RS232
• Other ports: 2 x 3.5mm (female) for bidirectional IR, 1x optical SPDIF for digital audio, 2x RJ45 Ethernet ports
• 1x 4K HDMI & USB Over IP Extender - Reciever (Transmitter not included)
• 1x IR Receiver
• 1x IR Transmitter
• 1x Multi-country power supply (EU, UK, US, AUS)
